Shandong Huaqi Automotive Technology Co., Ltd. is one of the leading manufacturers and suppliers of shacman f3000 tractor truck in China. If you're going to wholesale classy shacman f3000 tractor truck made in China, welcome to get free sample from our factory. All customized products are with high quality and low price.
Key Advantages of the SHACMAN F3000 Tractor Truck
High Reliability and Uptime: The core powertrain components-the "Big Three" (Weichai engine, Fast transmission, and Hande axle)-have been rigorously tested in real-world market conditions. They feature a low failure rate, facilitate easy maintenance and servicing, and are ideally suited for high-intensity, continuous operations.
Superior Heavy-Load Capacity and Off-Road Capability: The 6x4 drivetrain, paired with a high-ratio rear axle (commonly 4.111 or 4.769), delivers immense traction. This ensures excellent climbing ability and superior capability for extricating the vehicle from difficult terrain, making it the preferred choice for construction sites, mines, and unpaved roads.
Cost-Effectiveness: The chassis is robust and durable, offering a long service life. Furthermore, spare parts are highly interchangeable and affordably priced, resulting in overall maintenance and repair costs that are lower than those of premium-segment models.
High Adaptability for Customization: The chassis features a clean, organized layout with ample reserved space, making it easy to modify and convert into various specialized vehicle types-such as dump trucks, concrete mixers, heavy-haul transporters, and more.
Key Specifications (6x4, 430 HP, Standard Edition)
Basic Information
| Model Designation | SX4258JV324 |
| Drive Configuration | 6x4 |
| Wheelbase | 3175 + 1400 mm |
| Vehicle Dimensions | 6825 × 2490 × 3950 mm |
| Curb Weight | Approx. 8.8 tons |
| Max. Permissible Towing Mass | 40 tons |
| Max. Speed | 95 km/h |
Engine (Weichai WP12.430E50)
| Displacement | 11.596 L |
| Max. Horsepower | 430 HP |
| Max. Power Output | 316 kW |
| Max. Torque | 2060 N·m (1000–1400 rpm) |
| Emission Standard | China V / China VI |
Chassis Configuration
| Transmission | Fast 12JSD200TA (12-speed manual) |
| Rear Axle | Hande 13-ton dual rear axles |
| Rear Axle Ratio | 3.7 / 4.111 / 4.769 (Optional) |
| Tires | 12R22.5 |
| Fuel Tank | 400 L Aluminum Alloy Tank (Dual tanks optional) |
FAQ
1. Heavy Clutch Disengagement / Abnormal Noise
Causes: Pedal shaft or release fork shaft lacks lubrication and is binding; worn release bearing; obstructed pneumatic lines.
Solutions: Apply grease to the rotating shafts; replace the release bearing; inspect and clear the pneumatic lines.
2. Vehicle Lacks Power / Struggles on Inclines
Causes: Clogged air or fuel filters; poor fuel injector atomization; air leaks in the intake system; turbocharger malfunction.
Solutions: Replace the filters; clean or replace the fuel injectors; check the intake piping for airtightness; repair or overhaul the turbocharger.
3. Weak Brakes / Extended Braking Distance
Causes: Worn brake pads; air leaks in the brake lines; faulty brake wheel cylinders; air dryer failure leading to moisture ingress in the pneumatic system.
Solutions: Replace the brake pads; inspect and tighten lines to eliminate leaks; replace the wheel cylinders; regularly replace the air dryer and drain accumulated water from the air reservoirs.
4. Heavy Steering / Steering Wheel Vibration
Causes: Low power steering fluid level; worn steering universal joint; incorrect toe alignment; unbalanced tires.
Solutions: Top up the power steering fluid; replace the universal joint; adjust the toe alignment; perform tire balancing.
